60″ (152 cm) Z Master 4000 Series

TURBO FORCE® Cutting Deck
74054TA

$19,999 inc GST

Key product specifications

  • Deck 60" (152 cm)
  • Power 25.5 hp
  • Engine Kawasaki® FX801V (852cc) with Heavy-Duty Air Cleaner
  • Feature TURBO FORCE® Cutting Deck
  • 3 year / 2 year No Hour Limit
Find a local dealer
  • Overview
  • Features
  • Specifications

The Z-Master 4000 zero-turn mower is a force to be reckoned with. Built tough with a powerful 25.5 hp* Kawasaki FX801V engine, heavy-duty commercial grade hydros, flat-free semi-pneumatic caster tyres, 66 cm Voodoo Trac™ Tyres, and a 152 cm (60″) 7-Gauge High-Strength Steel TURBO FORCE® cutting deck paired with I-beam front end, tubular chassis and bumper to take on any job. Easy on and off with a deck step plate and anti-slip floormat. With the deluxe suspension seat, an hour meter, USB ports, phone holder, cup holder, and for after-hours work, powerful illumination with LED headlights, you’ll have everything you need to help you power through long days.

66 cm (26″) Voodoo Trac™ Drive Tyres

66 cm (26″) Voodoo Trac™ Drive Tyres

Get the ultimate in aggressive tread and styling and survey the task from a higher-vantage-point with 66 cm Voodoo Trac™ Drive Tyres.

LED Headlights

LED Headlights

Powerful illumination for after-hours work.

Up to 19.3 km/h

Up to 19.3 km/h

Get more done with ground speeds up to 19.3 km/h without reducing cut quality.

TURBO FORCE® Cutting Deck

TURBO FORCE® Cutting Deck

Enjoy years of reliable performance with a fully tubular frame and 7/10-gauge steel deck.

Rubber Discharge Chute

Rubber Discharge Chute

Trim close without damaging landscape structures or your chute.

Deck Step Plate

Deck Step Plate

Keep your grip and remove excess mud from your shoes with a deck step plate.

Clear Sightline to Rear Tyres

Clear Sightline to Rear Tyres

Clear sightline to rear tyres for enhanced control so you can clear a path without tyre spin.

Dual Capture Anti-Scalp Rollers

Dual Capture Anti-Scalp Rollers

Intelligently engineered dual capture anti-scalp rollers ensure the highest quality of cut in the harshest terrain you can throw at it.

Phone and Cup Holder

Phone and Cup Holder

Keep your phone and drink at arm’s reach.

USB Ports

USB Ports

USB ports to help you stay charged on the job.

Engine25.5 hp* Kawasaki FX801V (852cc) with Heavy-Duty Donaldson® Canister-Style Air Cleaner
Fuel Capacity37.9 litres
Blade Tip Speed18,500+ ft/min
Caster Tyres38 x 16.5 – 15.2 cm (15" x 6.5" - 6") Pneumatic
Deck Design60" (152cm) 7-Gauge High-Strength Steel TURBO FORCE®
Drive TyresVoodoo Trac™ 66 x 26.7 – 30.5 cm (26” x 10.5” – 12”)
ClutchElectromagnetic
Discharge ChuteRubber
Engine Displacement852cc
Foot Operated Height of CutStandard, 3.8 – 12.7 cm (.6 cm increments) 1.5" - 5.5" (.25" increments)
Ground Speed Up to 19.3 km/h
Horsepower25.5 hp*
Hour MeterStandard
IgnitionElectric
ROPSFolding
SeatDeluxe Suspension
Spindle BearingsMaintenance-Free
Spindle Housing22.9 cm (9") Diameter Aluminium
Steering Controls3.6 cm (1.4") Diameter Grips; Adjustable, Dampened
TransmissionZT-4400 Integrated Pumps & Wheel Motors
Warranty3-Year / 2-Year No Hour Limit**
Disclaimer*The gross horsepower of these engines was laboratory rated at 3,600 RPM by the engine manufacturer in accordance with SAE J1940 and SAE J1995. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly different.
